NO |
CODE |
DESCRIPTION |
NOTE |
EA |
ADDITIONнн |
|
|
|
WHEEL HOUSING |
FRONT |
|
SPORTQUATTRO |
|
1 |
859
809 101 |
WHEEL HOUSING |
LEFT FRONT |
1 |
|
|
2 |
859
809 102 |
WHEEL HOUSING |
RIGHT FRONT |
1 |
|
|
3 |
859
809 981 |
RETAINER FOR
CONNECTING ROD |
LEFT |
1 |
|
|
-3 |
859
809 982 |
RETAINER FOR
CONNECTING ROD |
RIGHT |
1 |
|
|
3A |
811 809 997 A |
SUB-PART -
WHEEL HOUSING |
LEFT FRONT |
1 |
|
|
(3A) |
811 809 998 A |
SUB-PART -
WHEEL HOUSING |
RIGHT FRONT |
1 |
|
|
4 |
859
803 109 |
SIDE MEMBER |
LEFT FRONT |
1 |
|
|
4A |
859
803 110 |
SIDE MEMBER |
RIGHT FRONT |
1 |
|
|
5 |
859
804 185 |
BRACKET |
LEFT |
1 |
|
|
-5 |
859
804 186 |
BRACKET |
RIGHT |
1 |
|
|
6 |
857
809 685 |
REINFORCEM. FOR
WHEEL HOUSING |
LEFT FRONT |
1 |
|
|
-6 |
857
809 686 |
REINFORCEM. FOR
WHEEL HOUSING |
RIGHT FRONT |
1 |
|
|
7 |
321 809 689 A |
REINFORCEMENT |
LEFT |
1 |
|
|
-7 |
857
803 531 |
REINFORCEMENT |
RIGHT |
1 |
|
|
8 |
859
803 157 |
FILLER PLATE
FOR LONGITUDINAL |
LEFT |
1 |
|
|
|
|
MEMBER |
|
|
|
|
9 |
857
809 025 |
GUSSET PLATE
FOR WHEEL HOUSING |
LEFT FRONT |
1 |
|
|
-9 |
857
809 026 |
GUSSET PLATE
FOR WHEEL HOUSING |
RIGHT FRONT |
1 |
|
|
10 |
859
803 029 |
BRACKET FOR
ENGINE |
LEFT |
1 |
|
|
11 |
859
803 030 |
BRACKET FOR
ENGINE |
RIGHT |
1 |
|
|
-12 |
811 809 109 A |
REINFORCEMENT
PLATE |
LEFT |
1 |
|
|
12 |
811 809 110 A |
REINFORCEMENT
PLATE |
RIGHT |
1 |
|
|
13 |
859
809 961 |
BRACKET |
|
1 |
|
|
14 |
823
863 187 |
COVER FOR
ENGINE COMPARTMENT |
|
1 |
|
|
15 |
823
863 203 |
CLIP |
|
8 |
|
|
|
05/84-07/87 01C |
SATIN BLACK |
|
|
|
|
16 |
803
803 583 |
PLUG |
30 |
12 |
|
|
17 |
803 803 583 B |
PLUG |
40 |
2 |
|
|
18 |
811
803 593 |
PLUG |
|
2 |
|
|
|
|
|
|
|
|
